EJOT® self-drilling screw JT3-2-4.9

JT3-2-4_9
JT3-2-4_9_nw_2016

Specification

  • Applications

    • Fastening profiled steel or aluminium sheets to timber substructures

  • Properties

    • A2 stainless steel with hardened drill point
    • Stainless steel sealing washer
    • Pre-assembled sealing washer

  • Technical specifications

    • Diameter: 4.9 mm
    • Drilling capacity tI + tII: 1.0 + 1.0 mm
    • Drive: Hexagon A/F8
    • Installation rotation speed: max. 1500 rpm
Order note: 70 mm screws with full length thread

Filter

Selected filters

    Orderidentifier Article Number ø mm Ø Sealing Washer mm Length mm Unit
    JT3-2-4.9x35-E16 3593511321 4.9 16 35.0 500

    Specifications

    ø
    4.9
    Ø Sealing Washer mm
    16
    Length
    35.0
    Fastener material
    Stainless Steel
    Orderidentifier
    JT3-2-4.9x35-E16
    Unit
    500
    JT3-2-4.9x35-E16 PU100 6593511321 4.9 16 35.0 100

    Specifications

    ø
    4.9
    Ø Sealing Washer mm
    16
    Length
    35.0
    Fastener material
    Stainless Steel
    Orderidentifier
    JT3-2-4.9x35-E16 PU100
    Unit
    100
    JT3-2-4.9x70-E16 3597011321 4.9 16 70.0 250

    Specifications

    ø
    4.9
    Ø Sealing Washer mm
    16
    Length
    70.0
    Fastener material
    Stainless Steel
    Orderidentifier
    JT3-2-4.9x70-E16
    Unit
    250
